Structural glazing folding door
WICSLIDE 75FD

Structural glazing for better design

Special care has been given to the finishes of the WICSLIDE 75FD for visual harmony both in open and closed position:

  • Profiles are flush
  • Visible structures sober and balanced
  • Black cladding of the vertical edges of the sashes, including the groove covers, hinges, carriage kit (roller), screws and gaskets
  • No beads and glazing gaskets

Modular space of places

With its very large dimensions which can reach 3 meters high and 12 meters long, WICSLIDE 75FD folding door is the ideal solution to partition the modular space of places of assembly. The outward folding door allows total opening, extending the living spaces

Technical characteristics:

  • Made with Hydro REDUXA 4.0 low carbon aluminium
  • Cradle to Cradle Silver Certification
  • Maximum sash dimensions: L 1200 mm x H 3000 mm
  • Maximum sash weight: 150 kg
  • From 3 to 10 sashes
  • Choice of central or lateral opening


Performances:

  • Thermal:

- Ud = 1.7 W/(m²K) with Ug = 1.1 W/(m²K)

- Ud = 1.4 W/(m²K) with Ug = 0.7 W/(m²K)

  • Air (NF EN 12207) - Water (NF EN 12208) - Wind (NF EN 12210): Class 4 – 7A – C3
  • Acoustic: Rw = 43 dB
  • Repeated opening / closing: Class 3 / 25,000 cycles, according to EN 12400


Intended market:

  • Top-of-the-range collective residential market
  • Tertiary
  • Car showrooms
  • Conference spaces
