Unitised façade
WICTEC 50 EL

The façade for specific demands

WICTEC 50 EL façade frame is adapted to:

  • Tall buildings
  • Buildings with limited access from the exterior


It is a technical design adaptable to each project and which is a solution for urban concentration, ideally matched to the increasing verticalization of the buildings. Each element of the WICTEC 50 EL façade can be individually adapted to the specific requirements of a project.


Credits: © Hufton+Crow

Improved productivity

A specific feature of the WICTEC 50 EL façade is that the “frames” or “glazed elements” can be entirely fabricated in the workshop. This process offers many advantages:

  • Quality of fabrication
  • Time saving and improved comfort, installation 4 times faster than a traditional curtain wall system
  • Optimized planning and management of the deadlines
  • Reduced on-site nuisance (noise, waste)
  • During renovation, some parts of the building can remain accessible during the work

Technical characteristics:

  • Made with Hydro CIRCAL 75R recycled aluminum profiles
  • Cradle to Cradle Silver Certification
  • System width: 50 mm
  • Maximum element dimensions: L 3000 mm x H 3500 mm
  • Drainage per module


Performances:

  • Thermal: Ucw up to 0.9 W/(m²K)
  • Air (NF EN 12152) - Water (NF EN 12154) - Wind (NF EN 13116): Class AE – RE1200 – 2000/-3200


Intended market:

  • Offices
  • Tall buildings


Availability date: first half 2020
